    Mortise Sash Lock 72Z Series

    Mortise Sash Lock 72Z Series

    Features
    • BS EN 12209 / DN 18251 / EN 1634-1
    • Fire Rated
    • CE Certified
    • Suitable for Fire / Non-Fire Rated Steel & Wooden doors
    • Compatible with Euro profile Cylinder
    • Double dead bolt throw

    Models

    SZi-5572Z : X=55mm
    SZi-6072Z : X=60mm
    SZi-6572Z : X=65mm
    SZi-5572Z : X=70mm
    SZi-5572Z : X=80mm

    Accessories

    • Strike pockets (Optional)
    • Lock and strike fixing screws

    Technical Data & Characteristics

    Center Distance 72mm
    Backset 55/60/65/70/80mm
    Lock case Galvanized Steel
    Latch SS304
    Dead Bolt SS304
    Follower SS304 8 x 8mm
    Forend Plate SS304 (SS316 optional)
    Forend Type Square edge or Round edge
    Striking Plate SS304 (SS316 optional)
    Latch Handing Field Reversible

    Dimension of Appearance
